Каталог запасных частей к технике: Golden Dragon XML6125CN-3150244. TOP COVER & SIDE PANEL
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | NHB02-2440W1220- FK34 | Fireproof board | |
| 2 | 6125Y14-5500200 | Cover | |
| 3 | CYC-002 | Safety hammer | |
| 4 | 6125Y14-8201010-1 | Curtain | |
| 5 | 5702-026B0 | End cover, sliding channel, curtain | |
| 6 | LXC1674A-6.3M | Curtian channel | |
| 7 | YF1031-2WAY-8 | Audio speaker | |
| 8 | 6125Y14-5709100 | Air duct assembly | |
| 9 | 6125Y14-5709410 | Gangway lamp assembly | |
| 10 | 6125Y14-5709400 | Mid roof panel assembly | |
| 11 | DS/910B-Y-H-A1 | Skylight assy | |
| 12 | L595 | Molding strip, mid roof | |
| 13 | 336.H3DKX-02C | Camera | |
| 14 | LXC1655-DV19 | Molding strip | |
| 15 | 6125Y14-5709020 | Rear roof assembly | |
| 16 | 6125Y12-5500150-DV19 | Cover | |
| 17 | 6125Y14-5500110 | Wire cover | |
| 18 | LXC1645A-6M | Strip | |
| 19 | 6125Y14-5709420 | Air outlet assembly | |
| 20 | 6125Y08-5709430 | Strip | |
| 21 | 5704-523-JD1 | Strip | |
| 22 | LXC2647A-5M | Profile | |
| 23 | GRM53-1500X285 | Damper plate | |
| 24 | JF-102N | Emergency valve | |
| 25 | 6125Y14-5709303 | Guided by brand | |
| 26 | 6125Y14-5709030 | Cooling air duct assy, above driver | |
| 27 | L550 | Strip | |
| 28 | 6125Y14-5709010 | Roof assy, front | |
| 29 | 06241111502 | Bus air duct and roof connection | |
| 30 | MZBHZ-6125 | Cover | |
| 31 | LXC2724A-6M | Aluminum profile |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
