Каталог запасных частей к технике: Golden Dragon XML6125CN-3150244. STEERING SYSTEM
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 6115E06-3402025 | Front vertical plate | |
| 2 | Q150B1235 | Hex bolt | |
| 3 | Q40112 | Plane washer | |
| 4 | Q40312 | Spring washer | |
| 5 | Q340B12 | Nut | |
| 6 | 6125Y13-3402501 | Mounting bracket, column | |
| 7 | 3402-303-B5F-B1 | Adjusting bracket | |
| 8 | 6155E01-3402100 | Steering transmission device | |
| 9 | Q150B1040 | Bolt | |
| 10 | Q40110 | Plane washer | |
| 11 | Q40310 | Spring washer | |
| 12 | Q340B10 | Nut | |
| 13 | 6125G11-3402024 | Front floor | |
| 14 | 7860955910 | Angle transmission | |
| 15 | 6125G10-3401120 | Steering drive shaft assembly | |
| 16 | 8098957112 | Steering gear | |
| 17 | 6125G10-3401011 | Steering pitman arm | |
| 18 | 6125V05-3401010-BZ02 | Drag-link assembly, front | |
| 19 | SC05-03002 | Outer house, rear | |
| 20 | SC05-03001 | Outer house, front | |
| 21 | 6155Y01-3774100 | Combination switch assembly | |
| 22 | 6937A16-3704100 | Ignition switch assy | |
| 23 | 3402-301-B5F | Dust boot, rubber | |
| 24 | SC02-0305-A | Compression ring, dust boot | |
| 25 | HFL1-6049-0000 | Steering wheel |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
