Каталог запасных частей к технике: Golden Dragon XML6125CN-3150244. AIR SUPPLY
1
2
3
4
4
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
18
18
19
20
21
22
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 6125Y26-3506102-FK31 | Copper pipe | |
| 2 | 6125M01-3555020 | Bracket, air dryer | |
| 3 | 4324100940 | Air dryer | |
| 4 | BOLM16-M22 | Straight adjustable thread elbow connector | |
| 5 | GWG16-600 | High temperature pipe | |
| 6 | 6100A-3500212 | Connector, air dryer | |
| 7 | 6100A-3500351 | Connector, PVC valve | |
| 8 | GB3759-G12 | Nut | |
| 9 | GB3764-12 | Thread | |
| 10 | 6115E11-3566010-BY33 | Bracket, condenser | |
| 11 | WA-3511060 | Condenser | |
| 12 | PAG6X1.5 | Pall tube | |
| 13 | GB3733.1-G6 | Straight connector, bite-type end | |
| 14 | 6125Y18-3500045 | Regeneration air reservoir | |
| 15 | XML3500185G6F0 | Bracket, copper pipe, air supply | |
| 16 | 35360010060 | Water drain valve, air cyinder | |
| 17 | 6125Y26-3506101-FK31 | Copper pipe, air supply | |
| 18 | GB3737.1-G16 | Straight thread connector | |
| 19 | 11R117-3500185 | Bracket, copper pipe, air supply | |
| 20 | GB3759-G16 | Nut | |
| 21 | GB3764-16 | Thread | |
| 22 | 4324070700 | Muffler |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
