Каталог запасных частей к технике: Golden Dragon XML6105CN-7150227. TOP COVER&SIDE PANEL
1
2
3
4
5
6
7
8
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | JYCRM30-2000X380 | Heat insulation fiber | |
| 2 | JYCRM40-2000X300 | Heat insulation fiber | |
| 3 | NHB02-2440W1220-FK34 | Fireproof board | |
| 4 | NLKD-5230A | Nylon buckle, covered pillar | |
| 5 | 6790H-5702013 | Roof plastic buckle | |
| 6 | 6105Y04-8250010-FK34 | Curtain | |
| 7 | 6720-360L | End cover, sliding channel, left curtain | |
| 8 | 5702-026B0 | End cover, sliding channel, curtain | |
| 9 | LXC1674A-6.3M | Curtian channel | |
| 10 | 5704-533-JD1 | Strip, sliding channel, curtain | |
| 11 | 6720-360R | End cover, sliding channel, right curtain | |
| 12 | CYC-002 | Safety hammer | |
| 13 | LXC1660-6M | Aluminum profile | |
| 14 | 6105Y04-5709130-FK34 | Door pump cover, middle door | |
| 15 | 5405-111-WA1 | Access cover | |
| 16 | L610 | Armrest profile trim strip | |
| 17 | 6105Y04-5709040-FK34 | Long carriage light assy | |
| 18 | YF1351-2WAY | Audible speake | |
| 19 | DS/910B-Y-H-A1 | Skylight assy | |
| 20 | ST1787-1600 | Bottom plate, molding strip | |
| 21 | ST1786-1600 | Cover plate, molding strip | |
| 22 | 6105Y04-5709400-FK34 | Mid roof panel assembly | |
| 23 | 336.H3DKX-02C | Camera | |
| 24 | L550-LYB | Moulding strip | |
| 25 | LXC-2738-1180 | LXC-2738-1.180 m | |
| 26 | 6105Y04-5709020-FK34 | Rear interior roof | |
| 27 | 6105Y04-5709520-FK34 | Corner piller, rear right | |
| 28 | 6105Y04-5709510-FK34 | Corner piller, rear left | |
| 29 | 6105Y04-5500110-FK34 | Trim cover | |
| 30 | LXC2724A-6M | Aluminum profile | |
| 31 | 6105Y04-5305405-FK34 | Wire cover I | |
| 32 | YYX-YLGJ | Medical box | |
| 33 | 6105Y04-5709010-FK34 | Inner roof assy, front | |
| 34 | 5702-004A0 | Rubber rim strip, inner roof | |
| 35 | 6105Y04-5709300-FK34 | Door pump cover, front | |
| 36 | JF-102N | Emergency valve | |
| 37 | LXC1621-6M-DT | 1621 profile terminal | |
| 38 | LXC1621-5M | 1621profile terminal |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
