Каталог запасных частей к технике: Golden Dragon XML6105CN-7150227. STEERING OPERATION BOOSTING PIPELINE
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 6155E01-3406011 | Clamp, power steering oil tank | |
| 2 | 7636472523 | Oil can assembly, steering assistant | |
| 3 | Q67522 | Clamp | |
| 4 | FYNYJG22X5 | Oil tube | |
| 5 | ZJKT-18-22 | Adjustable elbow connector | |
| 6 | JB982-27 | Sealing washer | |
| 7 | JB982-16 | Sealing washer | |
| 8 | XML3425301N9F0 | Straight thread connector | |
| 9 | GB3752.1-G14 | Straight thread elbow connector | |
| 10 | ZXGY13-14-10600 | High pressure oil pipeline, power steering | |
| 11 | 6155E01-3406502 | Transition connector, drain valve | |
| 12 | Y1-910-07-00-010 | Drain valve | |
| 13 | 6125G11-3406211 | Transition connector, drain valve | |
| 14 | ZXDY13-14-10800 | Low pressure oil pipeline, power steering | |
| 15 | ZJKT-18-22 | Adjustable elbow connector | |
| 16 | FYNYJG16X4 | Tube, oil-resist, pressure resist | |
| 17 | XML3425201K4F0 | Connector | |
| 18 | Q81714 | Connector | |
| 19 | Q81818 | Bolt | |
| 20 | JB1002-18 | Washer | |
| 21 | 6105E05-3408110 | Mounting bracket, steering oil tank |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
