Каталог запасных частей к технике: Golden Dragon XML6105CN-7150227. ELECTRICAL APPARATUS, FRONT INSTRUMENTS PANEL
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
19
20
21
22
23
24
25
26
27
28
29
30
30
31
32
33
34
35
36
37
38
39
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 6125Y12-5306100-CT07 | Master instrument panel assy | |
| 2 | DTC0-1381 | Digital recording equipment | |
| 3 | 385-40008-01B | wireless microphone | |
| 4 | 6155Y02-3725210-12 | Cigarette holder | |
| 5 | 6125Y12-5306200-CT07 | Sub instrument panel assembly | |
| 6 | VD-ZB279E-CNGRS-2050 | Combined instruments | |
| 7 | 202.A70JB-01C | MP3 Player | |
| 8 | 6125A12-3776400 | Color reversing monitor | |
| 9 | TD-10G-EN | Bus station broadcaster | |
| 10 | 1126-001E | High temperature alarm | |
| 11 | 6891-3735130 | Five-pin relay | |
| 12 | ZJ091 | Diode group | |
| 13 | DY-002 | Transformer | |
| 14 | 6125Y07-3700100-R0 | ELECTRIC BOX | |
| 15 | 6180Y01-3792431-DQ02 | Switch, ramp plate | |
| 16 | 6180Y01-3792432-DQ02 | Power switch, ramp plate | |
| 17 | MT203114 | Emergency exit switch | |
| 18 | JK967-4.18-189 | Electric fan switch | |
| 19 | 6125S3-3792120 | Fluorescence lamp switch | |
| 20 | 6125S3-3792220 | Reading lamp switch | |
| 21 | 6845Y01-3972080 | Signs switch | |
| 22 | 6145A01-3792680 | Rocker switch, exhaust fan | |
| 23 | 6125S3-3793000 | ECAS normal height indicator board | |
| 24 | 6125S3-3792930 | Body lifting switch | |
| 25 | 6125S3-3792010 | Night lamp switch | |
| 26 | 6125S3-3792690 | Rearview mirror defrost switches | |
| 27 | JK967-18.67-189 | CNG power switch | |
| 28 | 6145A01-3712120 | Diagnosis rocker switch | |
| 29 | 6845Y01-3792090 | Heater switch | |
| 30 | 6122A01-3792090 | Heater switch | |
| 31 | 6125S3-3792950 | Retarder switch | |
| 32 | JK967-AT-052 | Economic performance selector switch | |
| 33 | 6180H01-3793150 | The gearbox fault/hydraulic oil temperature | |
| 34 | ANL-004B1 | Manually start the fire extinguisher and alarm switch | |
| 35 | 6125S3-3792410 | Front door switch | |
| 36 | 6125S3-3792430 | Middle door switch | |
| 37 | 6937A16-3792130 | Emergency alarm switch | |
| 38 | 6125S3-3792680 | Horn change-over switch | |
| 39 | JK967-2.22-129 | Foglight switch, rear |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
