Каталог запасных частей к технике: Golden Dragon XML6105CN-7150227. AIR INTAKE SYSTEM
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 6116G92-1109230-EX36 | Under frame, air filter | |
| 2 | 6115G01-1109220 | Support assy, air filter | |
| 3 | AH24196 | Air filter | |
| 4 | KBZ-2A | Air filter blocking alarm | |
| 5 | GJGL-10212-11412-L | Silicone tube | |
| 6 | TXBG160 | T type clamp | |
| 7 | TXBG125 | T type clamp | |
| 8 | TXBG112 | T type clamp | |
| 9 | 6105Y12-1109401-FK34 | Pipe, steel, air intake | |
| 10 | GJGL-11414-15014-L | Rubber tube | |
| 11 | BWG-190-NR | Corrugated rubber tube | |
| 12 | BWBG190 | T type clamp | |
| 13 | GJGL-6313-8920-L | Silicone tube | |
| 14 | 6105Y12-1109501-FK34 | Pipe, steel, air intake | |
| 15 | GJG-89-140-L | Rubber tube, air intake, intercooler | |
| 16 | TXBG99 | T type clamp | |
| 17 | TXBG73 | T type clamp | |
| 18 | 6125G04-1119010G | Intercooler assembly | |
| 19 | GJGL-7012-8912-L | Rubber tube | |
| 20 | 6105Y12-1109701-FK34 | Pipe, steel, air intake | |
| 21 | GJGL-8925-8930-L | Silicone tube | |
| 22 | 6100A1-1109018 | Pipe clip, air intake, stainless steel | |
| 23 | 6100A1-1109064 | Fixing rubber ring, steel pipe | |
| 24 | 6103A54-1109713 | Fixing bracket, steel pipe |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
